Introduction

Features
- The industry’s fastest 3 inch rugged mobile label printer
- Built rugged to survive real-world industrial and retail environments
- Smart Printing capabilities support stand-alone printer applications, eliminating PC expense and complexity
- Two to three times faster time-to-first-label than competitive products
- Low cost of development, deployment and support
- Seamless integration with Intermec mobile computers and other mobile devices
- Secure wired and wireless communications options: Bluetooth®, 802.11 b/g, USB, Serial
- Label sensors minimize printing errors and reduce waste
- SmartSystems® remote device management reduces support needs
- Optimized for Intermec media, including linerless label media options

Printing

Print technology

Direct thermal

Maximum resolution

203 x 203 DPI

Print speed

101.6 mm/sec

Maximum printing width

7.2 cm

Paper handling

Core diameter

1.9 cm

Ports & interfaces

Connectivity technology

Wired & Wireless

Ethernet LAN

N

USB port

Y

USB 2.0 ports quantity

1

RS-232 ports

1

Performance

Internal memory

16 MB

Flash memory

64 MB

Certification

USA FCC Title 47, Part 15, Subpart B, Class B; Europe EMC Directive (EN55022 Class B + EN55024) ; CISPR22

Design

Product colour

Grey

Power

Battery type

Built-in battery

Number of batteries supported

1

Battery technology

Lithium-Ion (Li-Ion)

Battery capacity

2250 mAh

Battery voltage

7.2 V

Rechargeable

Y

Operational conditions

Operating relative humidity (H-H)

10 - 90%

Operating temperature (T-T)

-15 - 50 °C

Storage temperature (T-T)

-30 - 70 °C

Weight & dimensions

Width

127 mm

Depth

81 mm

Height

182 mm

Weight

828 g

Packaging content

Batteries included

Y

Warranty card

Y
